The thought
For some folks, merely sitting subsequent to a window can injury their pores and skin and result in delicate sunburn. So quite than lathering up in sunscreen each single day, Tim Alex Jacobs, who runs the location and YouTube channel mitxela, had the concept to make an amulet that his pal may put on to measure her UV publicity all through the day. Along with displaying the quantity of UVA radiation, it will additionally present the extent of UVB and the general UV index which might be cycled via by tapping the amulet.
Detecting ultraviolet radiation
To start the undertaking, Tim first had to determine the way to seize each bands of ultraviolet radiation ranges. The sensor he selected was the VEML6075 as a result of it claimed to assist detection of each UVA and AVB together with I2C connectivity, all in a small surface-mount bundle. However as Tim would later uncover, this sensor lacked sufficient documentation and solely captured two variants of the UVA spectrum. However on account of time constraints, he opted to maintain transferring ahead with the sensor.
Exhibiting the present UV ranges
With a option to detect UV gentle ranges, the subsequent step was to construct a show so the consumer can view the info. Tim had initially thought of an analog gauge, however as a result of additional complexity required, he determined to simply have a financial institution of eight LEDs for exhibiting the extent and three different LEDs that point out the kind of measurement: UVA, UVB, and the UV index (UVI). A single ATtiny84 microcontroller within the surface-mount QFN-20 bundle which was each compact sufficient to suit on a small PCB and had an ample variety of GPIO pins for driving the LEDs and sensor. For consumer interplay, a easy TTP223 capacitive sensing chip was added to the design that enables an individual to faucet a middle copper pad and change between the three viewing modes. Lastly, a CR2032 3V coin cell battery powers the entire machine.
PCB design
As one may count on, developing with a PCB that was each compact and simple to solder by hand was no straightforward process. Tim’s design contains a round board that has the financial institution of eight degree LEDs and the three mode indication LEDs opposing one another. On the highest half is the ATtiny84 and UV sensor whereas the underside half has the TTP223 capacitive contact sensor and some passive elements. The middle incorporates a round copper pad and the underside has a small spring that the battery rests towards for delivering present.
Making a housing
The housing for this particular amulet was hand crafted over many hours from a number of items of steel. A lathe was used to bore out a gap barely bigger in dimension than a CR2032 coin cell battery from a stable brass rod. As soon as accomplished, a number of threads have been added to the underside that permit for a stable cap to get screwed into place. Lastly, the attachment level was added to the highest by gentle soldering it to keep away from discoloring the brass.
Software program
Programming the amulet was fairly easy. When the TTP223 senses that somebody has touched the central copper pad, it sends a sign to the ATtiny84’s exterior interrupt pin that wakes it up from the deepest degree of sleep, which helps to tremendously preserve battery life. From there, UV values are learn from the sensor and used to calculate UVA, UVB, and UVI ranges that are then displayed on the LEDs relying on the at present chosen mode. After 15 seconds have elapsed, the microcontroller is put again to sleep till reawakened at a later time. You’ll be able to view the code for this undertaking right here on GitHub.
Closing meeting and testing
After ending the software program and the PCB, Tim added some closing touches to the amulet housing by masking the floor in electrostatic gold plating after which sprucing it to offer the amulet a pleasant shine. The assembled PCB was dropped into place and gentle soldered to the housing which connects it to the battery’s floor terminal and helps to carry it in place. You’ll be able to view Tim’s wonderful construct log and demonstration video right here on YouTube to see the amulet working simply as supposed.
